Specialized veterinary vehicle

A specialized veterinary vehicle for on-site biosterilization of stray animals.

bullet_icon
Base chassis

Volkswagen Crafter, MAN TGE, Mercedes Sprinter, Ford Transit

bullet_icon
Purpose

On-site biosterilization of stray animals

bullet_icon
Price

By individual calculation














The panels and the roof of the van are made of 50mm-thick sandwich panels. The outer covering of the panels is plastic, 2 mm thick. The inner covering of the panels is also plastic, 1-1.5 mm thick. Insulator – extruded foam polystyrene, type PPSB-S-35, 40 mm thick. The panels are connected to the frame elements using special structures and adhesives. All external seams of the body are treated with a special sealant. All outer corners are edged with aluminum corners. Additionally, all hidden cavities at the bottom of the body are treated with protective mastics and pastes. Door fittings of the body (hinges, doors, locks and latches) are industrially manufactured from stainless steel. The equipment is conveniently placed on the shelves, has its own place and can be easily accessed. Tables, cabinets, work surfaces fixed on the walls and floor for carrying out work and placing the necessary equipment are made of stainless steel. All cabinets with doors, shelves with doors and drawers are equipped with latches (locks) protecting from spontaneous opening, both in the moving and in the static position of the vehicle. All sharp objects, as well as stationary installed equipment, have technological protection while the vehicle is moving. The operating table is conveniently located for conduction surgeries. Stationary equipment, equipment and locks for doors, dampers are protected from accidental opening. The positioning and attachment points of the equipment provide reliable fixation for convenience and safety during removal and installation. Hot and cold water supply system with sink, fresh cold water tank and waste water tank are also included. Hot water supply is provided by a boiler with a 15-liter water tank.

The positioning of operating equipment and equipment in the compartments incorporates the tactics of its operational use according to its functional purpose, namely:

  • tool table;
  • washstand with electric water heater;
  • waste water tank, water tank;
  • lighting means;
  • drug safe;
  • cabinet for surgical instruments;
  • electrical equipment and the like.

All equipment is individually positioned and secured with latches.

Fastening mechanisms provide reliable fastening of all equipment during the movement of the vehicle, regardless of the terrain.

The superstructure design provides high resistance to torsional dynamic loads and vibrations.

Standard configuration:

  • Adjustable veterinary operating table;
  • Tool table;
  • Air sterilizer GP-20;
  • Condensate evaporator (dissipator) for the air conditioner;
  • Diesel air heater;
  • Pharmaceutical refrigerator;
  • Drug safe;
  • Mono / bipolar electrosurgical coagulator;
  • Operating reflex lamp;
  • Animal clipper;
  • Veterinary portable oil-free suction;
  • Oxygen Concentrator;
  • Pulse Oximeter / Patient Monitor;
  • Vacuum cleaner for collecting animal hair;
  • Cages for animals;
  • Water heater;
  • Tail lift.

* Standard configuration depends on the base vehicle and can be configured by the customer.

leo_image


01 00







Characteristic

The panels and the roof of the van are made of 50mm-thick sandwich panels. The outer covering of the panels is plastic, 2 mm thick. The inner covering of the panels is also plastic, 1-1.5 mm thick. Insulator – extruded foam polystyrene, type PPSB-S-35, 40 mm thick. The panels are connected to the frame elements using special structures and adhesives. All external seams of the body are treated with a special sealant. All outer corners are edged with aluminum corners. Additionally, all hidden cavities at the bottom of the body are treated with protective mastics and pastes. Door fittings of the body (hinges, doors, locks and latches) are industrially manufactured from stainless steel. The equipment is conveniently placed on the shelves, has its own place and can be easily accessed. Tables, cabinets, work surfaces fixed on the walls and floor for carrying out work and placing the necessary equipment are made of stainless steel. All cabinets with doors, shelves with doors and drawers are equipped with latches (locks) protecting from spontaneous opening, both in the moving and in the static position of the vehicle. All sharp objects, as well as stationary installed equipment, have technological protection while the vehicle is moving. The operating table is conveniently located for conduction surgeries. Stationary equipment, equipment and locks for doors, dampers are protected from accidental opening. The positioning and attachment points of the equipment provide reliable fixation for convenience and safety during removal and installation. Hot and cold water supply system with sink, fresh cold water tank and waste water tank are also included. Hot water supply is provided by a boiler with a 15-liter water tank.

The positioning of operating equipment and equipment in the compartments incorporates the tactics of its operational use according to its functional purpose, namely:

  • tool table;
  • washstand with electric water heater;
  • waste water tank, water tank;
  • lighting means;
  • drug safe;
  • cabinet for surgical instruments;
  • electrical equipment and the like.

All equipment is individually positioned and secured with latches.

Fastening mechanisms provide reliable fastening of all equipment during the movement of the vehicle, regardless of the terrain.

The superstructure design provides high resistance to torsional dynamic loads and vibrations.

Standard configuration:

  • Adjustable veterinary operating table;
  • Tool table;
  • Air sterilizer GP-20;
  • Condensate evaporator (dissipator) for the air conditioner;
  • Diesel air heater;
  • Pharmaceutical refrigerator;
  • Drug safe;
  • Mono / bipolar electrosurgical coagulator;
  • Operating reflex lamp;
  • Animal clipper;
  • Veterinary portable oil-free suction;
  • Oxygen Concentrator;
  • Pulse Oximeter / Patient Monitor;
  • Vacuum cleaner for collecting animal hair;
  • Cages for animals;
  • Water heater;
  • Tail lift.

* Standard configuration depends on the base vehicle and can be configured by the customer.
